HY-BIO-ELITE
Hydraulic system lubricant
Hydraulic system lubricant - 4L is backordered and will ship as soon as it is back in stock.
Safety Data Sheet
Safety Data Sheet
Compatibility
Compatibility
Instructions for use
Instructions for use
Notes
Notes
Technical Data
Technical Data
Technical specifications
Technical specifications
| Characteristics | ASTM Test | Typical Values Hy-Bio Elite #15 | Typical Values Hy-Bio Elite #22 | Typical Values Hy-Bio Elite #32 |
|---|---|---|---|---|
| Flash Point | D92 | 210°C | 232°C | 230°C |
| Fire Point | D92 | n.d. | 278°C | 282°C |
| Pour Point | D97 | <-60°C | <-57°C | -47°C |
| Density at 15°C | D4052 | 0.9194 g/cm3 | 0.989 g/cm3 | 0.9124 g/cm3 |
|
Viscosities @ -30°C @ -20°C @ 0°C @ 40°C @ 100°C |
D445 |
n.d. n.d. n.d. 14 cSt 3.5 cSt |
1939.03 cSt 682.05 cSt 157.23 cSt 22 cSt 4.7 cSt |
6417.4 cSt 1917.8 cSt 301.3 cSt 30.2 cSt 5.6 cSt |
| Viscosity Index | D2270 | 144 | 134 | 126 |
|
Hydrolytic Stability - water acidity - weight loss - blade appearance |
D2619 |
n.d. n.d. n.d. |
1.6 mg KOH 0 mg/cm2 1b |
0.8 mg KOH 0 mg/cm2 1a |
| Copper Strip Corrosion | D130 | n.d. | 1b | 1b |
|
Foaming Stability - sequence #1 - sequence #2 - sequence #3 |
D892 |
n.d. n.d. n.d. |
0/0 ml 0/0 ml 0/0 ml |
10/0 ml 5/0 ml 20/0 ml |
|
Demulsibility - water in oil - free water - emulsion |
D2711 |
n.d. n.d. n.d. n.d. |
A 0.20% 42 ml 2.5 ml |
A 1.30% 37 ml 2.0 ml |
|
Oxidation Stability - pressure drop after 100h. |
D525 modified | n.d. | n.d. | 7 psi |
| Oxidation Stability | D943 | n.d. | >10000 hrs. | 8500 hrs |
|
Biodegradability - CEC L-33-T-82 (28 days) - CEC L-33-T-82 (21 days) - Predictive (21 days) |
D7373 |
75% n.d. n.d. |
n.d. >80% 68% |
n.d. 85% n.d. |
|
Rust Resistance - distilled water (A) - seawater (B) |
D665 |
n.d. n.d. |
Pass Pass |
Pass Pass |
| 4-Ball Wear | D4172 | n.d. | n.d. | 0.35 mm |
|
4-Ball Extreme Pressure - load index - weld load |
D2783 |
n.d. n.d. |
n.d. n.d. |
22 160 kg |
| Dielectric Breakdown Voltage | D877 | 40 kv | 29.8 kv | 31 kv |
| High Temperature Oxidation Resistance | D2272 | n.d. | 491 min | n.d. |
| Iodine Value (ISO 3961) | D5554 95 | n.d. | 5.8 cg/g | n.d. |
Hydraulic system lubricant
Description
Description
HY-BIO Elite is the best performing biodegradable lubricant for hydraulic systems on the market. Its unique formula, exclusive to PROLAB, provides it with exceptional properties that allow it to outperform all plant-based or synthetic biodegradable products and even certain standard mineral oil-based lubricants.
Features and Benefits
HY-BIO Elite biodegradable and eco-friendly lubricant for hydraulic systems has a unique formulation, based on 100% high-performance eco-synthetic oil with a premium antioxidant additive. Thus, it stands out for its superior thermal stability, its excellent resistance to hydrolysis (it degrades very little in the presence of water), load, oxidation (between 5000 and more than 10000 hours depending on the grades) and corrosion, in addition to having excellent low-foaming characteristics. Thanks to its very low pour point and high viscosity index, it offers better lubrication and superior performance at all temperatures.
HY-BIO Elite is ENVIRONMENTALLY FRIENDLY: biodegradable and ecological, it contains no heavy metals, organochlorines or nitrous compounds.
It is formulated to meet OECD 301B, OECD 201-202 and 203 standards and is composed of a minimum of 80% renewable materials.
HY-BIO Elite is SAFE as it is not regulated under WHMIS and is available in five ISO grades: #15, #22, #32 and #46.
Types of Applications
HY-BIO Elite is essential in any hydraulic system exposed to an ecological risk in the event of an accidental spill: work near waterways, port facilities, marine equipment, forestry, agriculture, etc.
In addition, when low temperature conditions are encountered, HY-BIO Elite #22 becomes an excellent choice.
